Board-X Ups Offline 850va 360W Internal Battery 1x 12v 7ah
-Power: 850VA
-Output: Simulated Sine Wave
-Frequency: 50/60HZ
-Voltage: 220V
-Battery: 1x 12V/7AH Sealed Inside
By buying this product you can collect up to 28 loyalty points. Your cart will total 28 points that can be converted into a voucher of $0.28.
Best Price Guaranteed
Delivery all over Lebanon
Daily Updated Website
| Board-X Ups Offline 850va 360W Internal Battery 1x 12v 7ah | |
| Capacity (VA/Watts) | 850/ 360 |
| INPUT | |
| Nominal Input Voltage | 110/120Vac or 220/230/240 Vac |
| Operating Voltage Range | 81-145Vac/162-290 Vac |
| Operating FrequencyRange | 50/60 Hz (1±10%) |
| OUTPUT | |
| Output Voltage range (Batt. Mode) | Simulated Sinewave at nominal voltage ±10% |
| Frequency Range (Batt. Mode) | 50 Hz or 60 Hz ± 1 Hz |
| Transfer Time | Typical 2-6 ms, 10ms max. |
| BATTERY | |
| Battery Type & Number | 12V/7Ah x 1 |
| Typical Recharge Time | 6-8 hours ( To 90% capacity) |
| PROTECTION | |
| Full Protection | Overload and overcharge protection |
| INDICATORS | |
| Indicators | AC Mode, Battery Mode, Load Level, Battery Level |
| ALARM | |
| Battery Mode | Sounding every 10 seconds |
| Battery Low | Sounding every second |
| Overload | Sounding every 0.5 second |
| Battery Replacement Alarm | Sounding every 2 seconds |
| Fault | Continuously sounding |
| Management | |
| USB & RS-232 port(Optional) | Supports Windows® 2000/2003/XP/Vista/2008, Windows® 7, Linux, Unix, and MAC |
| Environment | |
| Operating Temperature | 0- 40°C |
| Humidity Range | 0-95 % (Non-condensing) |
| Noise Level | <40db (1 meter from surface) |
| PHYSICAL | |
| Dimension, W x D x H (mm) | 101×298×142 |
| Net Weight (kg) | 4.25 |
| STANDARDS | |
| Safety | IEC/EN62040-1;IEC/EN60950-1 |
| EMC | IEC/EN62040-2;IEC61000-4-2;IEC61000-4-3;IEC61000-4-4;IEC61000-4-5;IEC61000-4-6;IEC61000-4-8 |
UPS l07
Data sheet
- Output Capacity
- 360 W
- Battery
- Internal
